EFFICIENT
Controlled Energy Use
Engineered to maximise air output with minimal energy use, lowering operational costs.
Reliability
100% Duty Cycle
With a 100% duty cycle, it delivers continuous high-pressure performance for demanding applications.
flexibility
Up to 40 bar
Offered in 25-bar and 40-bar options with adaptable features to suit unique operational needs.
Advanced Booster Pump
Imagine a booster pump that’s been engineered to give you maximum output without maxing out on energy use. This advanced in-house designed pump is at the core of each booster, pushing air and nitrogen to high pressures with remarkable efficiency.
With this technology, you are getting a solution that works as hard as you do, keeping operational costs low and productivity high. It is reliability and efficiency, built right in.
Why Choose the BstAIR 40?
For today's industries, getting high-pressure output is not an option. That's why we've created a booster range that stands out by its power and flexibility.
These machines present different features that streamline maintenance and provide enhanced control so that you can be sure of being equipped to handle high-pressure tasks effortlessly.
Choose this booster for dependable performance you can count on, day after day.
- High-Efficiency Booster Pump
Delivers exceptional air output with minimal energy consumption.
- IE3 Motor with IP55 Protection
Built to withstand harsh environments, this motor ensures reliable and durable performance.
- Integrated Aftercooler
Lowers air discharge temperature for applications needing high-quality air, available in the Full Feature model.
- Airlogic2T Controller
An intuitive touchscreen interface that provides live monitoring and easy control over key performance metrics.
- Custom-Engineered Reed Valves
Specifically designed for each model, these valves boost performance while reducing energy use.
- Efficient Lubrication System
Built-in oil channels ensure all critical areas are well-lubricated.
- Oil-Level Safety Switch
Automatically shuts off if oil levels drop, protecting your equipment from potential damage.
- Inlet Particle Filter
Reduces the risk of contamination, keeping your equipment safe and performing at its best.
- ECO6i Controller
Synchronises multiple boosters for balanced operation, optimising energy use and wear for extended equipment life.
- High-Pressure Line Filters
Ensures clean and high-quality air by filtering contaminants, ideal for sensitive applications.
- High-Pressure Condensate Drains
Manages condensate effectively to maintain optimal performance, especially in humid environments.
- Service Kits
Convenient kits with original parts to keep your booster running smoothly and reliably for years.
Get in touch today!
You want to boost your performance while reducing your energy footprint ? We've got you covered. Contact us for more informations about our air and nitrogen boosters solution.
Technical data
POWER
7.5-30
Efficient power options from 7.5 to 30 kW allow for meeting various operational needs with low energy use.
FAD
264.6
High delivery up to 264.6 l/s maximizes productivity, ideal for high-pressure tasks.
PRESSURE
10
Handles up to 10 bar, integrating seamlessly with standard air systems for smooth performance
| Model | Power (kW) | Max Inlet Pressure (bar) | Max Discharge Pressure (bar) | Free Air Delivery (l/s) |
|---|---|---|---|---|
| bstAIR 10-40 | 7.5 | 10 | 40 | 34.7 |
| bstAIR 15-40 | 11 | 10 | 40 | 48.5 |
| bstAIR 20-40 | 15 | 10 | 40 | 63.8 |
| bstAIR 25-40 | 18.5 | 10 | 40 | 77.5 |
| bstAIR 30-40 | 22 | 10 | 40 | 94.2 |
| bstAIR 40-40 | 30 | 10 | 40 | 124.8 |
For full technical specification and more information refer to product brochure
