Refrigerant dryers

DW ES Refrigerant Dryer

What are the two most important criteria when selecting a compressed air dryer? It’s air quality and operational costs. Worthington Creyssensac’s DW ES cycling dryer delivers on both. With a stable pressure dew point as low as 3°C, it gives you a reliable supply of premium, dry air. But that’s not all ! Discover more about this range by reading on.

air quality

Compliance with ISO standards

This range ensures a stable pressure dew point as low as +3°C, as well as a constant purity class level 4, according to ISO 8573-1:2010.

low operational costs

Less energy consumption

Cycling technology cuts energy consumption during intermittent use.

sustainability standards

Zero Depletion

The DW ES was designed to minimise your environmental impact thanks to CFC-free refrigerants.

PRODUCT OVERVIEW

Adopt your Ultimate Solution for Dry Air

The DW ES cycling dryers have been developed for exceptional performance and combine energy efficiency and reliability. They maintain consistent air quality with advanced cycling technology, achieving a pressure dew point as low as +3°C while optimising energy usage.



Offering flexibility across industrial applications, this range includes 11 models with capacities from 360 to 5700 l/min. Equipped with elements like a hot gas bypass valve and electronic condensate drains, these dryers are built to perform reliably, even in challenging conditions.

Refrigereant Dryer DW ES50 Worthington Hero

Cyclic Operation

The DW ES range is built with smart cycling technology that adjusts its performance to match your air demands seamlessly.

Here’s the game-changer: it only kicks into action when needed, which means less energy wasted during light loads and lower operating costs for you.

The result? Consistently high-quality air, optimised energy use, and a system that works smarter.

Empowering excellence through diversity

By cultivating an environment of diversity, inclusion and well-being, we empower every individual to contribute their unique perspectives, fueling innovation and fostering a culture where everyone thrives.

people and diversity

FULL OF FEATURES

Hot gas bypass valve and Heat Exchanger

Hot gas bypass valve – Maintains a stable pressure dew point to prevent freezing during low-load conditions.

Heat exchanger – Engineered for effective pre-cooling while keeping pressure drops to a minimum.

ES510 FS Worthington Creyssensac

Why Choose the DW ES range?

The DW ES range combines unbeatable performance and energy efficiency, ensuring your air stays dry and high-quality without high energy costs.

This series of dryers is the reliable, cost-effective solution you can count on to keep operations running smoothly, conceived with durable components to withstand even the harshest conditions and offering a wide selection of models to meet various needs.

MORE FEATURES

Electronic Condensate Drain and Airlogic 2T Controller

Electronic condensate drain – Operates only when necessary, thus limiting air loss and improving overall system efficiency.


Airlogic 2T Controller
– Provides advanced performance monitoring and management for your DW ES, featuring graphic screens, data logging, and storage capabilities. Also the risk of downtime is minimised thanks to service alerts and shutdown alarms.

Airlogic2T Controller

  • Hot gas bypass valve
    Stabilises pressure dew point and prevents freezing at lower loads.

  • Fan switch
    Optimises the pressure dew point at very low temperatures.

  • Electronic condensate drain
    Prevents compressed air waste by opening only when needed.

  • Heat exchanger
    Designed for optimal pre-cooling and minimise pressure drops.

  • Cycling technology
    Cuts energy consumption during intermittent use.

  • Airlogic 2 Graphic Controller
    Conceived with user-friendly graphic screens, data logging and storage and allows to realise important energy-savings thanks to dual pressure band time scheduling and start/stop timers.

Get in touch today!

With so many air treatment products available, finding the right solution can seem challenging. Our specialists are here to simplify the process and deliver options that match your exact requirements. Get in touch with us for expert advice and tailored recommendations.

Technical data

Power consumption

890

These dryers are designed for maximum efficiency, reducing energy consumption while delivering exceptional performance.

Air treatment capacity

5700

This series provides versatile air treatment to fit different type of needs and requirements.

PRESSURE

16

Be sure of getting reliable and consistent performance.



Model Max. Working Pressure (bar) Air Treatment Capacity (l/min) Power Consumption (W) Inlet/Outlet Connections Dimensions (A x B x C) (mm) Weight (kg) Refrigerant Gas
DW 2 ES 16 360 200 3/4" M 393 x 525 x 521 27 R513 A
DW 5 ES 16 900 330 3/4" M 393 x 525 x 521 32 R513 A
DW 9 ES 16 1500 410 3/4" M 393 x 525 x 521 34 R513 A
DW 14 ES 16 2400 570 1" M 393 x 716 x 675 56 R513 A
DW 21 ES 14 3600 700 1" M 792 x 500 x 680 80 R410 A
DW 34 ES 14 5700 890 1" M 792 x 500 x 680 107 R410 A

For full technical specification and more information refer to product brochure

DW ES Refrigerant Dryer

DW ES Refrigerant Dryer

Full product range

Filename
WCO_DW_2-364_ES_Sales_Leaflet_EN.pdf
Size
1 MB
Format
pdf
Download

Contact us !

If you're searching for the ideal air treatment solution or need assistance selecting the right setup for your operations, we’re here to help. Contact us today for expert and personalized advice suited to your specific requirements.
